Single Sided FR4 Copper Clad Laminate Prototype Circuit Board Assembly

Name: Single Sided FR4 Copper Clad Laminate Prototype Circuit Board Assembly
Brand: FASTPCBA
Price: 0.1 USD

Wholesale Single Sided FR4 Copper Clad Laminate Prototype Circuit Board Assembly from china suppliers

Brand Name : FASTPCBA

Model Number : Flexible PCBs FR4 Manufacturing

Certification : ISO13485, IATF16949, ISO9001

Place of Origin : China

MOQ : 1PCS

Price : USD 0.1-3/ pcs

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100000pcs/month

Packaging Details : 1.Inner: PCB: Vacuum Packing PCBA: ESD Packing 2.Outer: Standard export carton 3.Customized package.

Name : Single Sided FR4 Copper Clad Laminate Prototype Circuit Board Assembly

Keyword : Printed Circuit Board Assembly Services

Service : One-stop Service

Layer Count : 1-48

Testing Service : Function Test, 100% Test

MOQ : No MOQ

PCBA Test : X-ray,AOI Test,Functional test

Min line/space : 0.075/0.075mm

Surface Treatment : HASL, HASL Lead Free, Immersion Gold, Immersion Tin, Immersion Silver, Hard Gold, Flash Gold, OPS…

ROHS : CANEC1308721101

Process Characteristics : HDI Blind Buried Hole Process, High BGA Density, Small Hole-To-Line Spacing

Solder mask : Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue

Contact Now

One-Stop Fast Pcba Service Single-Sided Copperclad Laminate Pcb Board And Pcb Assembly

We offer parts sourcing service to cater to requirement of top-quality PCB assembly. Over a decade's experience allows us to maintain such a long-standing and stable cooperative relationship with authorized electronic components manufacturers or distributors that customers can expect instant and low-cost parts sourcing service. We promise: definitely NO fake parts will be provided. Furthermore, 100% rigorous quality inspections have to be carried out prior to real applications of components just to ensure their reliability in PCBA. Moreover, to be fully compatible with your PCB assembly service demand, flexible alternatives can be obtained in PCBCart. You can either fully depend on us for parts sourcing service or buy through your own channel then sent to us for PCB assembly. No matter which way to choose, we all promise 100% quality inspection on each piece of component before their use.

* PCB Processing Capacity:

Base Material	Normal Tg FR4, High Tg FR4, PTFE, Rogers, Low Dk/Df etc.
Solder Mask Color	Green, Red, Blue, White, Yellow, Purple, Black
Legend Color	white, yellow, black, red
Surface treatment type	ENIG, HASL, HAF, HAF LF, OSP, flash gold, gold finger, sterling silver
Max. layer-up(L)	50
Max. unit size (mm)	700*460mm
Max. & Min. board thickness (mm)	0.3/12
Board thickness tolerance (mm)	T<1.0mm: +/-0.1mm; T≥1.0mm: +/-10%
Min. mechanical drilling hole (mm)	0.15
Min. laser drilling hole diameter(mm)	0.075
Min. innerlay clearance(mm)	0.15
Min. hole edge to hole edge space(mm)	0.28
Max. finished copper thickness(um)	Outer Layer: 420 (12oz) Inner Layer: 210 (6oz)
Min. & Min. trace width (mm)	0.075 (3mil)
Solder mask thickness (um)	line corner : >8 (0.3mil) upon copper: >10 (0.4mil)
BGA pad (mm)	≥0.25 (HAL or HAL Free:0.35)
V-CUT blade position tolerance (mm)	+/-0.10
Impedence tolerance (%)	+/-5%
Min. legend width (mm)	0.1
Fire flame calss	94v0


* PCBA Processing Capacity:

Processing Service	One Stop PCB Assembly service, include components & plastic mold sourcing, SMT&DIP assembly and enclosure installation service.
SMT Assembly	5 SMT Lines(10 million chips per day (0402, 0201 with 8 million per day)
DIP Assembly	3 Production Lines(1.2 million pcs per day)
Cable & Wire Assembly	Standard & Customized
Enclosure Assembly	3 Production Lines(Each line has 15 assemblers and 2 quality control engineers)
Components Package	Smallest with 01005, various chips package as QFN,BGA,SSOP,PLCC,LGA
Testing	E-test, Probe flying, Function testing, Temperature cycling, X-ray, AOI
Equipment	DSP1008, XPM2820,YG200,YV88-XG, YV100XGP, UNI-AX8200,WS-4501,XPM2820
Conformal Coating	Yes
PCBA Packing	Bubble, Anti-Static package (or in your requirement)
MOQ	No MOQ(1PCS)
Factory Certificate	IATF16949, ISO13485, ISO9001

Single Sided FR4 Copper Clad Laminate Prototype Circuit Board Assembly

International Equipment:

Single Sided FR4 Copper Clad Laminate Prototype Circuit Board Assembly

FASTPCBA is the most powerful turnkey assembly factory which accumulates more than 20 years experience. We can manufacture and assemble 1-48 layers full feature pcba like: FPC, Rigid, HDI, BGA, heavy copper, alum, metal core pcb, high frequency, rigid-flex pcb, single/ double sided pcb, multilayers pcbs.

All pcba out of FASTPCBA has obtained certificates of ISO9001, ISO13485, ISO14000 and IATF16949. Customers from industrial pcba, medical pcba, automotive pcba, smart home pcba, communication pcba, military pcba and aerospace pcba prefer to cooperate with us in recently years.

FASTPCBA has developed and become stronger depended on high quality pursuit. With good reputation all over the world, our smt workshop work day and night to pursue punctual pcba delivery for customers over 50 countries.
